ModelQ6 Edge® 2.0

Drive ConfigurationMid-wheel drive

Drive Wheels14" Solid
Optional: 14" Pneumatic
Optional: 14" Knobby

Caster WheelsFront: 6" Solid1
Rear: 6" Solid1

Anti-Tip WheelsN/A

Maximum Speed4Up to 6.25 mph13

Ground Clearance2.7" (battery tray)

Turning Radius520.5"

Overall Length1132.23"

Base Width24.4"

Seating SizesTRU-Balance® 3
Synergy®/Static: W: 10-22" D: 10-22"
Power Tilt: W: 12-22" D: 12-22"
Lift & Tilt: W: 12-22" D: 12-22"
TRU-Balance® Flex Seat
W: 15-22" D: 15-20"

Seat-to-Floor Heights16,17TRU-Balance® 3
Synergy®: 15.875-20.875"
Static: 16.5-18.5"
Lift & Tilt8: 17.5-19.5"
TRU-Balance® Flex Seat: 16.5-18.25"

Battery Size6 NF-22 (2)

Battery Weight 38 lbs.

Available Electronics 75A Q-Logic NE
75A Q-Logic NE+
120A Q-Logic 3 EX
120A Q-Logic 3e

Battery Charger 8A Off-board

Motor Packages 2-pole Mid-Wheel 6®

Weight Capacity 300 lbs.

Base Weight 138.6 lbs.

Q6 Edge® 2.0 Features

• 6.25 mph high-speed motors standard
• Responsive handling
• Precise control
• Advanced performance
• Bold aesthetics
• Optional iLevel's patented Extra Stability Technology® enhances safety while performing transfers, reach, and numerous other activities of daily living
• Optional iLevel® enables up to 12" of seat elevation while at walking speed (up to 3.5 mph)
• iLevel is retrofittable on the Q6 Edge® 2.0
• Available with Accu-Trac Advanced Tracking Technology
• Optional LED fender lights (standard with iLevel)
• Available with WC19 crash-test approved occupied transit kit option on tilt & recline and iLevel
